Gareth Jones on Depeche Mode's new album "Exciter" and on Emagic Logic


Martin Gore told in an interview with the U.S. Keyboard magazine, that he recorded everything in Logic Audio...

Yes, Logic Audio was used extensively in the production and pre-production of "Exciter". Martin wrote the chords and vocal melody and lyrics usually on guitar or piano. He then came to Paul Freegard and myself with a simple song demo played on guitar or piano and we helped arrange it and orchestrate it in his home studio. Later in the production we built a portable setup for Martin with a small mixer and a couple of synths in a rack running off a powerbook. This was obviously convenient because it was so small, and Martin left the country to write 'Easy Tiger' and 'Love Theme' using a powerbook with Logic Audio.

What were the main-advantages of recording digitally with Logic Audio?

The digital input of the Audiowerk8 card allowed me to hook up a high quality recording chain (Focusrites and Apogee) to the computer in Martin's home studio, which meant everything was recorded in excellent quality so there were no quality issues later. In this way the demos could seamlessly grow into the finished production. This meant arrangements were flexible and it was easy to transfer audio to Mark Bell or anyone else who needed to work on the tracks. Also we were able to keep everything backed up in original quality very easily, which was reassuring as we travelled around. Indeed vocals, guitars, synths and samples from the pre-production were used on the final CD. The whole approach was fluid. At this stage a G4 running Logic Audio (Motu 2408) and two Unitors was the "nerve centre" of the whole process. The final version of the songs for mixing was again constructed in Logic Audio, with the fx that we wanted "bounced" so that we could give the mix engineer multiple audio files for import to his PT system.

Which plugins were used?

Logic plugins were used extensively including the compressor, the tape delay, bitcrusher, overdrive and distortion, and Autofilter, Spectral Gate and the occasional Reverb. Some FAT EQ as well Hi pass and Lo Pass Filters were also used. Also lots of other VST plug-ins. By the way: "Exciter" was the album where I really discovered SoundDiver &emdash; it was a great tool to create sounds and also to store them &emdash; and helped me in my task of being able to locate every sound used, whenever necessary.




Gareth Jones on "Exciter" gear

(from Keyboard magazine, by Greg Rule)

What gear did you use?

Emagic Logic Audio was the center of my work on the album. One of the reasons I was asked to join the pre production team was my Logic skills. I was also using a Novation Supernova and a Nord Micro Modular as sound sources. When we left the pre-production phase, everything was either recorded in Logic Audio, or running off these synths and an Akai S3200. Martin has a bunch of synths in his studio, and we used a Nord Lead (Paul was the Nord programming guru), Roland JV-2080, JP-8000, and JD-800 (Martin was the JD-800 programming guru), Minimoog, ARP 2600, Wasp Stinger (featured on the chorus of "Shine"), EMS AKS synthi (featured on 'The Dead of Night'), Jomox X-Base module, Quasimidi Rave-o-lution (on which we created the original mood for 'When the Body Speaks'), Korg MS2000, and others I may have forgotten. Guitars were recorded through the Line 6 Pod, which I enjoyed using with Emagic SoundDiver software. SoundDiver also played an important role in keeping track of everything. Microphones were largely Shure SM57 and B&K 4006. We also ran my Laptop with Native Instruments Absynth and Reaktor, Hyperprism, Logic Audio with Cycling 74 Pluggo and other VST plug-ins, including Waves Renaissance, plus Propellerhead Recycle, Bias Peak, Roxio Toast, etc. My MAQ 16/3 sequencer and Regelwerk were massively useful controllers. I was using native audio on Macs with VX pocket cards on the laptops and initially an AW8 card on an old beige &emdash; then, later, a MOTU 2408 on a G4. I used my Focusrite ISA 115HD feeding my Apogee AD500e, sometimes through my Focusrite ISA 131 compressor. So basically I had one or two recording chains only, usually on flying leads so I could pick up any sound from either Martin's AMEK desk or the Mackie 32-8s that we used in the live rooms of the studios we worked in later. This kept things simple, which I like. Mark Bell was also interested in, and comfortable with, this style of working, so in the production we set up a 56-channel Mackie with a G4 desktop running Logic, Mark's laptop running Steinberg Cubase with virtual synths (including TC Works Mercury and Waldorf Wave), and my laptop running whatever. In the control room we ran Digidesign Pro Tools on an Apogee AD8000 where Dave was recording vocals. Everything was word-synced. The output of my e fed the G4, Mark's laptop, his E-mu IV XTurbo sampler, and my laptop. Also hooked up was Mark's Akai MPC2000, my S3200, an MS2000, the Supernova, and Nord Modular. Work on the songs would vary from Mark working alone on the stereo output of his laptop to more conventional multi-channel setups depending on what we needed to be doing. We exchanged data between machines on Zip and CDs with sneakernet. Martin had a setup based around a laptop running Logic in the booth as well, so we had three work areas, reasonably isolated acoustically but with good visual contact. This enabled us to be fluid and try all kinds of things very easily; it was easy to offer and get perspective from different members of the production at any time.


(by Jonathan Miller )

Depeche Mode is still regarded from some quarters as a synth band, yet" Excite"r doesn't immediately come across as a synth-dominated album per se. What's more important to the Depeche Mode sound of today: synths or samplers?

A real mixture of these two things &endash; anything and everything available, really. Both are very important, in my opinion. Akai and E-mu samplers were used extensively, as were all kinds of VST plugs &endash; Logic plug-ins, Pluggo, Hyperprism, and a wealth of TDM plug-ins. In addition to the synths we had in the studio we brought recordings of quite a few others from the Hertfordshire sessions &endash; AKS Synthi, Minimoog, JP-8000, Stinger, ARP 2600, Rave-O-Lution, JoMox drum box and JD-800. Mark also came with a lot of recordings of his synths &endash; in E-mu format &endash; and we recorded his DX11 on 'I Feel Loved'. VST instruments used included Reaktor, Mercury and PPG Wave 2.V."

Electric Eel's Kevin van Green (also responsible for creating customized recording spaces for ex-band members Alan Wilder and Vince Clarke, Mute boss Daniel Miller, and former Depeche producer Flood) has told me that Gore's Hertfordshire-based private studio is sited in a double garage and featured a custom cabinet housing three vintage ARP 2600 analogue synthesizers at the time of its construction. What can you tell us about this studio now?

Martin has a nice collection of gear &endash; Akai samplers; AKS Synthi, as featured on 'Dead Of Night'; two rack Minimoogs; Roland JD-800, JP-8000 and JV-2080; Nord Lead, Wasp Stinger, featured on the chorus of 'Shine'; Moog Series III; three ARP 2600s; JoMox drum module; lots of guitars; piano; a G3 running Logic Audio; Amek desk, with quite a few guitar effects and different bits and pieces that I've probably forgotten. It's a pleasant, spacious room, with lots of daylight and a view of trees and countryside.





Gareth Jones on his gear

"
Over the years I have tried loads of gear, obviously, and at present I am focusing on a reduced equipment set including:

Software

Logic Audio, Recycle, Metasynth, MESA, Peak, Rebirth, Pluggo, Hyperprism, SonicWorx (for their amazing Time Designer plug-in), SoundDiver, Reaktor, Reason, Mercury, PPG wave 2.v, Pro 52, B4, VB1, M-Tron. Waves Renaissance bundle.
Netscape, Eudora, Quickeys & Retrospect and Action Files are also in daily use of course
The Logic user group and daw-mac are also invaluable resources for me, as was Napster (what a great music library that was) and my BT Openworld ADSL connection

Hardware

Akai S3200, Novation SuperNova & BassStation & DrumStation, Nord Micromodular, Doepfer MAQ 16/3, Regelwerk and MS404 and the Pocket Control, and Roland TB606
Apogee 500e A/D, Focusrite ISA115HD & ISA 131(Rupert Neve versions) , TC Finalizer, B&K 4006 mics, Schoeps Collete series mics, Genelec 1029A monitors
Sherman Filterbank, Line6 POD, Roland RE501 Chorus Echo, Waldorf 4 pole filter
Apple G3 Powerbook, Digigram VX pocket, EMI 2/6, E-Magic Unitor II, and the wonderful MT4
My Soundcraft Spirit Folio Notepad is in (almost!) daily use
Palm Pilot is also a major part of my life and my Creative Nomad mp3 player & SONY CD walkman are great tools.
Here is a more comprehensive list of my gear

Manufacturer

Model

Type

Akai

ME-35T

trigger/midi

Akai

S3200 32,dig i/o

sampler

Apogee

500E

A to D

Apogee

PS1000

power suppply

Apple Mac

M5343

powerbook G3

APS

SCSI Sentry 1

Interface

Boss

Dr Beat DB66

metronome

Boss

flanger

gtr foot pedal

Boss

phazor

gtr foot pedal

Boss

TM3

mixer

Bruel & Kjaer

4006

Microphone

Bruel & Kjaer

4006

Microphone

Bruel & Kjaer

4007

Mic omni

Color sound

Tremolo

foot pedal

Digidesign

Universal Slave Driver

Digi sync

Doepfer

MAQ 16/3

Sequencer

Doepfer

MS 404

Instrument

Drawmer

201

Gate

Drawmer

Midi Gate

Gate

Dunlop

Cry Baby

Foot Pedal

E Magic

Unitor8 Mk2

Interface

E Magic

Logic Audio

Software

Electro Harmonics

electric Mistress

flang/filter matrix foot pedal

Electro Harmonics / Sovtex

Small stone

footpedal

emagic

unitor2

interface

epson

stylus color 760

printer

Fender

Midi Twin MT-10

Amp

Focusrite

ISA 131

dynamics

Focusrite

ISA115hd

stereo eq/mic pre

Focusrite

PSU120

p/s for ISA 115hd

Genelec

1029A

speaker

Hewlett Packard

HP Surestore DAT C5653A

SCSI tape drive

imation

superdrive

drive

iomega

jazz

drive

iomega

zip2

drive

Kenton Electronics

Pro 2

midi-cv box

korg

05R/W

Instrument

line6

pod

effect

Midiman

Midisport

USB interface

Mogami

.

mic cables

Musitronics

Mu-Tron

phasor

Nakamichi

ZX7

Cassette Machine

Native Instruments

Reaktor

software synth

Neumann

BS945

battery phantom p/s

Neumann

BS945

battery phantom p/s

Neumann

CMV3

Microphone

Neumann

M7

Mic capsule

Neumann

M8

Mic capsule

Neumann

M9

Mic capsule

Neumann

NKM

P/S

Neumann

torpedo head

MIc Capsule

nord

micromodular

synth

Notron

sequencer

midi seq

Novation

Bass Station

Instrument

Novation

Drum Station

Instrument

Novation

Supernova

synthesizer

Panasonic

RX-DS45

ghetto blaster

Q Logic

Midi Bar Counter

counter

Rockman

chorus Dly

Fx unit

Rockman

Distortion

Fx unit

Rockman

X100

fx

Roland

Re501

tape delay

Roland

TB 303 modified

Bass Line

Roland

TB 606

Instrument

Schoeps

BLM3

Capsules

Schoeps

BLM3

Capsules

Schoeps

CMTS501U

stereo mic

Schoeps

Collette CMC1

Microphone

Schoeps

Collette CMC1

Microphone

Schoeps

Collette CMC1

holder x2

Schoeps

DZC

PAD

Schoeps

DZC

PAD

Schoeps

MK21

Capsules

Schoeps

MK21

Capsules

Schoeps

MK21H

Capsules

Schoeps

MK21H

Capsules

Schoeps

MK4

Capsule

Schoeps

MK4

Capsules

Schoeps

MK4

Capsules

Schoeps

MK8

Capsules

Sennheiser

Popper Stopper

pop shield

sherman

filterbank

filter

Shure

SM57

Microphone

Shure

SM57

Microphone

sony

ecm 959A

microphone

Sony

ECM101SM

Microphone

Sony

ECM121

Microphone

Sony

ECM50PB

Microphone

Sony

ECM727P

microphone

Sony

ECM909

Microphone

Sony

ECM939LT

microphone

sony

MDRCD550

headphones

sony

MDRCD850

headphones

Sony

Mic

ECM95A

Sony

RMRD3

interface

Sony

Tcd-7

DAT Player

Sony

wdm6

Pro Walkman Cassette

Soundcraft

Spirit Folio

Mixer

StudioMaster

MA36

Midi Tester

Surrey Electronics

.

stereo mic amp

Tascam

DA30 DAT Machine

Tape Machine

TC Electronic

Finalizer

mastering processor

Technics

SL1210 mk2

record deck

Waldorf

mini work 4 pole

midi filter

WEM

copicat

tape echo

Zoom

9030

Digital MultiEffect






.
.
