RECORDING / PLAYBACK
Recording Medium 3.5 inch, hard disk (E-IDE type)
Recording Format FDMS-3 ((Fostex Disk Management System-3
Save/Load Format FDIO-1 (Fostex Data In Out-1)
Sampling Frequency 44.1kHz
Quantization 16-bit linear (Non expanded)
A/D Converter 20-bit 64 times, over sampling, Delta-Sigma
D/A Converter 24-bit 128 times, over sampling, Delta-Sigma
No. of Recording Track 16 real tracks + 8 additional tracks
Simultaneous Recording 16 tracks
Vari Pitch Control +/- 6%
Crossfade 10msec.
Frequency 20Hz ~ 20kHz

INPUT / OUTPUT
Input 1 ~ 6 ø6mm Phone jack (Unbalanced)
Input Impedance 50kohm or more (Unbalanced)
Standard Input Level -50dBV ~ 2dBV
Input 7 and 8 ø6mm Phone jack (Unbalanced)
XLR-3-31 type (Balanced)
Input Impedance 50kohm or more (Unbalanced),
10kohm or more (Balanced)
Standard Input Level -50dBV ~ 2dBV
Phantom Power (XLR only) +48VDC (On/Off with SETUP mode)
Output (Tip)
Load Impedance 10kohm or more
Input Level -10dBV
Insert Input/Output ø6mm TRS Phone jack,
(Output (Tip), Input (Ring))
Load Impedance 10kohm or more
Input / Output Level -10dBV
Monitor Output ø6mm Phone jack (Unbalanced)
Load Impedance 10kohm or more
Output Level -10dBV
Headphone ø6mm TRS Phone jack
Load Impedance 10ohm ~ 50ohm
Output Level 20mW or more (at 16ohm)
AUX Send 1 + 2 ø6mm TRS Phone jack
(Tip: Send 1, Ring: Send 2)
Load Impedance 10kohm or more
Output Level -10dBV
Stereo Out L, R RCA pin jack
Load Impedance 10kohm or more
Output Level -10dBV
Digital In/Out 2 x Optical
Format ADAT optical / IEC60958 (S/P DIF)
MIDI In/Out 2 x DIN 5 pin / MIDI standard
Punch In/Out 1x ø6mm phone jack

GENERAL
Dimensions 402 (W) x 110 (H) x 370 (D) mm
Weight Approx. 6.1kg
Power Supply 120VAC 60Hz, 230V~ 50/60Hz
(AC inlet type)
Power Consumption 22W
